SMITH Electric Forklift Truck XE25A 2500 kg 300 cm

SMITH Electric forklift XE25A 2500 kg 300 cm

High-performance, easy-to-handle electric forklift for moving loads in any setting

This electric forklift, powered by a battery, is an excellent solution for tough work environments. Its compact build is perfect for working in confined aisles and limited spaces. The double telescopic mast is designed for lifting up to 2500 kg, and the strong motor and reliable battery deliver consistent performance over time.

• Outstanding performance and superior maneuverability
• Optimal load distribution
• Hydraulic lift cylinders
• Quiet hydraulic lifting system
• Steering wheel can be adjusted
• Reduced emissions

The XE25A electric forklift is designed for both indoor and outdoor use. With its easy-to-handle controls and adjustable steering wheel, operators can move and lift loads up to 3000 mm with ease. The forklift features a powerful motor and a robust 48V/600Ah battery, providing extended run time and quick charging capability.

SMITH Electric forklift XE25A 2500 kg 300 cm technical details

SMITH Electric forklift EA video



Key features of the XE25A electric forklift

• The steering system receives prioritized energy flow for precise and responsive steering
• Dual front wheel brakes provide dependable stopping power and help reduce the risk of accidents
• The rolling duplex telescopic mast stays stable while moving and delivers secure load handling
• The advanced hydraulic system delivers smooth forklift operation and maintains safety in unexpected situations
• Side battery access makes replacement quicker and simpler, supporting continuous use and greater productivity
• A dual electric system offers quiet, efficient, smooth, and safe vehicle control
• The smart panel gives clear navigation, quick troubleshooting, and easy setup for the entire vehicle system
• Performs reliably in a variety of environments, withstanding temperatures from -25°C to +40°C, up to 100% relative humidity, and elevations up to 1200m

Excellent value

With its impressive capacity, maneuverability, and robust construction, powered by advanced hydraulic, steering, and battery systems, the XE25A electric forklift delivers outstanding value and dependable performance in tough work settings.

High-performance, durable, and easily swappable battery

The 5PZS600 battery model features a 600Ah capacity and 48V voltage, providing consistent performance and long-lasting durability. When a battery change is required, the process is simple and offers two options: side or overhead removal. For side extraction, another forklift is used to remove the battery. For overhead extraction, a transfer cart is used to pull and replace the battery. Since the XE25A electric forklift uses a relatively lightweight battery, side extraction is recommended for safe and efficient battery replacement.

The battery supports normal forklift operation in ambient temperatures from 0°C to 40°C, and can be discharged in temperatures ranging from -25°C to +55°C.

Dependable controls for safe operation

The XE25A electric forklift offers precise operational control to promote safety and productivity.

This electric forklift is equipped with a CURTIS controller, ZAPI ACE2 motor, and Inmotion controller. The CURTIS controller uses high-frequency MOS tube technology, providing excellent speed control, enhanced safety, intelligent operation, and strong protection. The controller system includes a travel controller, contactor unit, and accelerator. The lifting system uses dual-speed pump control, which operates without mechanical contacts, minimizing start-up shock and extending service life.

Intelligent display

The XE25A electric forklift is equipped with an intelligent display connected to the vehicle system through a CAN bus. This display provides diagnostics and allows configuration of the entire vehicle system. Operators can view or adjust module settings to maintain peak performance and minimize risk.

The interface allows users to navigate the main screen or submenus and shows details such as battery charge, vehicle speed, current mode, and traction hour meter.

Adjustable travel modes help optimize movement and battery efficiency. The forklift operates in three selectable modes: standard economy mode (E), power mode (P), and slow mode (S).

The smart panel interface enables operators to identify errors or malfunctions by displaying fault information, allowing the operator to stop the machine and prevent further damage.

Simple operation and maneuverability

This nimble electric forklift delivers strong performance and must be operated by trained and certified personnel. To ensure proper use, only qualified staff should perform maintenance and repairs on the machine and its components.

1.

   Inspect the control and alarm systems before use. If any parts are damaged or malfunctioning, operations should be suspended until repairs are completed.

2. Fully insert the forks under the load and keep the load balanced on both forks. Do not lift with only one fork. Avoid lifting loads that exceed the rated capacity.
3. Start, turn, drive, brake, and stop the forklift smoothly. Always slow down, especially when working on wet or slippery surfaces.
4. Keep the load as low as possible while driving, and tilt the mast back for added stability.
5. Use caution when operating the forklift on slopes. For slopes greater than 1/10, drive forward when ascending and in reverse when descending. Do not turn the forklift on a slope. Do not load or unload goods while driving downhill.
6. Stay alert for pedestrians, obstacles, and uneven ground while operating the forklift.
7. Do not transport loads that are unsecured or stacked loosely. Use caution when moving oversized items.
8. Before leaving your seat, engage the hand brake and make sure it stays engaged. Lower the forks to the ground, shift to neutral, and turn off the engine or disconnect the power.
9. If parking the forklift on an incline, set the parking brake and secure it. For extended parking, place wheel chocks under the tires.

SMITH Electric forklift EA features

• Zero Emissions
• No Pollution
• Minimal vibration
• Low operating expenses
• High efficiency
• Superior quality

The SMITH electric forklift line uses advanced 3-phase full AC technology, featuring the Italian ZAPI electric controller, ZAPI-SUPEREC AC motor, HAKWER battery, and a high-performance hydraulic system. These components make material handling easier and more cost-effective.

The Energy Regeneration Function increases working hours by 15%, supporting demanding and extended operations.
